500lph Ultrafiltration Water Treatment Plant Industrial Ultrafiltration Membrane Filters

500lph Industrial Ultrafiltration Membrane Filters Ultrafiltration Water Treatment Plant

Specifications

UF membrane water treatment plant system for water purification

UF system is a solution separation device in which an UF membrane fiber is used a filtration medium, membrane two side's pressure difference as a driving force. The UF membrane is only allows the solvent(such as water molecules), mineral salts and small molecular organic substances in the solution to pass through, and the macromolecular substances such as suspended matter, colloid, protein and microorganisms in the solution are intercepted, Thereby achieving the purpose of purification or separation

UF description

UF processes are currently limited by the high cost incurred due to membrane fouling and replacement. Additional pre-treatment of feed water is required to prevent excessive damage to the membrane units.

Quartz Sand Filter
It uses quartz sand as filter medium, effectively intercept to remove the suspended solids in the water, organic matter, colloid particles, microorganism, chlorine, smelling and some heavy metal ions, etc., finally to reduce water turbidity, purify water quality.

Activated Carbon Filter
activated carbon is used for both removing organic constituents and residual disinfectants (such as chlorine and chloramines) from water. We make media always by coconut shell which is the best quality media.
Activated carbon filter can effectively remove color, odor, residual chlorine, organic matter and heavy metals, synthetic detergent, such as bacteria, viruses and radioactive pollution.

Water softener
A water softener can be used to help prevent scaling in an RO system by exchanging scale forming ions with non scale forming ions. As with a MMF unit, it is important to have a 5 micron cartridge filter placed directly after the water softener in the event that the under drains of the softener fail.
Water softener is used to remove calcium and magnesium, and some other metal cations in the hard water.

Ultrafiltration (UF)

Ultrafiltration (UF) is a variety of membrane filtration in which forces like pressure or concentration gradients lead to a separation through a semipermeable membrane.Suspend solids and solutes of high molecular weight are retained in the so-called retentate, while water and low molecular weight solutes pass through the membrane in the permeat (filtrate). This separation process is used in industry and research for purifying and concentrating macromolecular (103 - 106 Da) solutions, especially protein solutions.

Flow chart

Pictures
