1500L/Hour Water Treatment Softener System RO System 7.5KW 380V

1500L/Hour Water Treatment Softener System RO System 7.5KW 380V

ro system and water softener 7.5KW

1500L/hour Water Treatment Softener System

380V ro and water softener

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Product Name:
RO Purified Drinking Water Production Plant / Small Ro Water Treatment Equipment
Material Of Housing:
Anti-corrosive Carbon Steel Or Stainless Steel
Place Of Origin:
Core Components:
Pump, Bearing, PLC, Membrane
After Warranty Service:
Video Technical Support, Online Support, Field Maintenance A
Applicable Industries:
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
Wooden /Box
Delivery Time
Payment Terms
L/C, T/T, Western Union
Supply Ability
1000 Sets /Month
Product Description

 1500L RO Purified Drinking Water Production Plant / Small Ro Water Treatment Equipment




item 1500L RO Purified Drinking Water Production Plant / Small Ro Water Treatment Equipment
Brand name LDD-1500lph
operating weight 2500kg
Overall dimensions

Floor area: 14 square meters

Voltage 380V/7.5KW
Warranty 1 Year
After-sales Service Provided Video technical support, Online support
Material SUS


Control mode full-automatic
Inlet water quality

Groundwater, surface water, urban tap water




Reverse osmosis water purification equipment

Anti-penetration water purification equipment, anti-penetration is a new type of modern pure water treatment technology, cleanliness almost 100%, so people call this water production machine for anti-penetration pure water dispenser.


Application introduction

The reverse osmosis water purification equipment passes the raw water through a fine filter, a granular activated carbon filter, a compressed activated carbon filter, and then through a pump, using a pore size of 1/10000μm (equivalent to 1/6000 of Escherichia coli, 1/300 of a virus) Reverse osmosis membrane (RO membrane) turns high-concentration water into low-concentration water.


At the same time, it isolates industrial pollutants, heavy metals, bacteria, viruses and other impurities mixed into the water, so as to meet the specified physical and chemical indicators and health standards for drinking. , produces clean to pure water, which is the best choice for the human body to replenish high-quality water in time. Because the purity of water produced by RO reverse osmosis technology is the highest among all water production technologies mastered by human beings, the purity is almost 100%, so people call this water production machine a reverse osmosis pure water machine.

Reverse Osmosis (RO) is a new and modern technology for treating purified water. Reverse osmosis components are used to increase water purity and remove impurities and salts. The purified water we use every day is treated by reverse osmosis equipment, and the water quality is clear.

Quartz Sand Filter
It uses quartz sand as filter medium, effectively intercept to remove the suspended solids in the water, organic matter, colloid particles, microorganism, chlorine, smelling and some heavy metal ions, etc., finally to reduce water turbidity, purify water quality.

Activated Carbon Filter
Activated carbon is used to remove organic components and residual disinfectants such as chlorine and chloramines from water. We always make our media out of coconut shell, which is the best quality media.

Activated carbon filters can effectively remove color, odor, residual chlorine, organic matter and heavy metals, synthetic detergents, such as bacteria, viruses and radioactive contamination.

Water softener
A water softener can be used to help prevent scaling in an RO system by exchanging scale forming ions with non scale forming ions. As with a MMF unit, it is important to have a 5 micron cartridge filter placed directly after the water softener in the event that the under drains of the softener fail.
Water softener is used to remove calcium and magnesium, and some other metal cations in the hard water.


Precision filter

Precision filter (also known as the security filter), the shell is generally made of stainless steel, and the interior uses PP melt-blowout, wire burning, folding, titanium filter element, activated carbon filter element and other tubular filter element as the filter element. Different filter elements are selected according to different filter media and design process, in order to meet the requirements of water quality.

Reverse osmosis membrance (RO)

Reverse osmosis membrane is a kind of artificial semi-permeable membrane which simulates biological semi-permeable membrane and is the core component of reverse osmosis technology. Reverse osmosis technology principle is higher than the osmotic pressure of the solution, according to other substances can not pass through the semi-permeable membrane and these substances and water away. The membrane aperture of reverse osmosis membrane is very small, so it can effectively remove dissolved salts, colloid, microorganisms, organic matter and so on. The system has the advantages of good water quality, low energy consumption, no pollution, simple technology and easy operation.


Flow chart


1500L/Hour Water Treatment Softener System RO System 7.5KW 380V 0


1500L/Hour Water Treatment Softener System RO System 7.5KW 380V 1

1500L/Hour Water Treatment Softener System RO System 7.5KW 380V 2

1500L/Hour Water Treatment Softener System RO System 7.5KW 380V 3

Foreign installation and training

1.Timely Delivery,considerate sales after service

2.Many Years quality warranty,OEM service.

3.Top Craftmanship, All products 100% tested

4.Preferential freight by Famous shipping company

5.New Design,Very popular style products recommendation for your local market.


After-sales Service

1. Starting from the date of the equipment installation is complete, free warranty for 12 months, overseas projects since the factory warranty from the date of 18 months

2. Warranty period of product problems, the seller free of charge and is responsible for transport costs

3. If the buyer need to on-site service, both sides talks things over solve.

4. Man-made or natural disaster damage caused by the seller to provide free telephone support, for service, the seller may be appropriate to charge the cost

5. If you need to extend the warranty period, the two sides resolved through consultation.
