Place of Origin:
China
Brand Name:
Leader-t/OEM
Certification:
CE/ISO
Model Number:
LD-250LPH
Contact Us
Reverse osmosis water treatment is a technology that passes through (through) membranes with the help of selection using return pressure as the driving force.
For membrane separation technology, when the system and the pressure are greater than the osmotic pressure of the aqueous solution, water molecules continuously pass through the membrane, flow into the central tube after water is produced, and finally discharge the impurities in the membrane Water, such as ions, and organic matter, such as bacteria and viruses, are trapped on the inlet side of the membrane, and then flow out in concentrated water to achieve separation and purification.
Configuration list | |||
Configuration | Material | SPEC | Brand |
---|---|---|---|
Tank | FRP /SS | 844/725/1065etc | Domestic/Pentair etc. |
Value | / | Auto/Manual | Domestic/Pentair etc |
Filter | quartz sand | 20-80 mesh | Domestic |
Active Carbon | 600-1100Mg/g | Domestic | |
Resin | / | Domestic PUROLITE,Rohm Hass | |
Ro membrance | Cellulose acetate membrane,element | 1812/2521/2540,4040/8040 etc.. | VONTRON/DOW,HYDRANAUTIC/Dongli |
Controlling System | / | PLC ,Maunal,Electric control | Domestic,Siemens |
Pipe/Value | Upvc/ss304/ss316 | DN15-DN150 | Domestic |
Pump | SS/Iron/Copper | CNP,Grundfos | |
Optional | Customize the design according to the customer's URS | ||
Application | Drinking, cleaning, beverage, industrial and mining enterprises and so on. |
Sichuan Leader-t Water Treatment Equipment Co.,Ltd is a professional enterprise integrating research,design,production,sales, installation and after-sales service of medical water treatment equipment..The medical water treatment equipment,harmaceutical water treatment equipment and laboratory water treatment equipment produced by the company are used in medical institutions, bio-pharmaceutical,scientific research institutions,testing centers and other units.The company has a group of experienced technicians and water treatment engineers, who have developed a variety of water treatment equipment with rich experience and advanced technology.The company can also provide integrated services such as engineering design, equipment installation and commissioning, maintenance and operator training according to the needs of users.Company covers an area of 4,000 square meters.The production workshop is completely designed and constructed in accordance with the GMP requirements for medical device production;The company has a perfect management system and operating mechanism to provide customers with high-quality, fast, and satisfactory service.Adhering to the responsibility and trust, the company is willing to seek common development with customers and build a platform.
