Place of Origin:
China
Brand Name:
Leader-t/OEM
Certification:
CE/ISO
Model Number:
LD-UF
Contact Us
Hollow Fiber Ultrafiltration Uf Membrane Filtration Unit RO System Accessories
Specifications
Module | UF-4021 | UF-4040 | UF-8040 |
Size (mm) | Ø101×533.4 | Ø101×1016 | Ø201.9×1016 |
Module type | Inside-out | Inside-out | Inside-out |
Shell and seal materials | PVC,epoxy resins | PVC,epoxy resins | PVC,epoxy resins |
Membrane Material | PAN | PAN | PAN |
Max operating pressure psi(Mpa) | 43(0.3) | 43(0.3) | 43(0.3) |
Suggest operating pressure psi(Mpa) | <15(0.1) | <15(0.1) | <15(0.1) |
Max trans-membrane pressure psi(Mpa) | 29(0.2) | 29(0.2) | 29(0.2) |
Operating temperature | 5~40℃ | 5~40℃ | 5~40℃ |
Effective membrane area | 4m2 | 2m2 | 18m2 |
Design flux | 40-150L/m2/h | 40-150L/m2/h | 40-150L/m2/h |
Main Features
-Save 50% occupying area compared with traditional system.
-Relative high MLSS value(smaller than 15g/L)and long residue time for sludge (smaller than 60days).
-Stable producing water quality for different inlet water.
-Less sludge residue reduces cost for sludge treatment.
-Low energy consumption, simple cleaning and low operation cost.
-Simple installation and easy operation, the whole set can be placed underground with auto-control
Application Range
1. Pure and ultrapure water equipment,
2. No bacterium no heat raw water equipment for pharmacy,
3. Purification for beverage, drinking water and mineral water,
4. Separation, concentration and purification in industry
5. Wastewater treatment, electrophoretic coating, electroplating, oil wastewater treatment, etc.
