Promotional Household 50G 70G Ozone Generator Water Purifier High Efficiency

Promotional Household High-Efficiency Water Purifier Ozone Generator RO System Accessories

Products Description

Environmental requirements for using this product
1.1 There should be no flammable and explosive gas and conductive dust in the room. It is forbidden to install in hazardous areas where ammonia gas is easy to leak or explosion hazard
1.2 There is 220V/50HZ AC power supply indoors. Some ozone equipment also needs 380V/50Hz AC power supply
1.3 Ambient temperature requirements: -10℃-33℃
1.4 Environmental humidity requirements: ≤55%.
1.5 The ground on which the machine is placed must be flat, pay attention to placing the machine on the ground or on a support
steadily.
1.6 Keep the working environment of the equipment ventilated and dry during equipment installation. Exhaust fans or air conditioners must be installed in this space. Water cooling needs to be connected to cooling water and chiller.

Operation method of air source ozone generator
1. Place the ozone generator in a specific (stable, well-ventilated and heat-dissipating) position outside the room to be disinfected, and check the ozone silica gel Whether the hose is connected to the ozone outlet of the machine. 2. Connect the cooling water system and pay attention to the correct connection of the cooling water inlet and outlet. (This type is a water cooler).3. Connect the other end of the hose to the jet or mixing tower, if not, don't connect it. 4. The ozone outlet should bemore than one meter higher than the water level to prevent backwater. 5. Turn on the power, the power indicator light is on, and the voltmeter displays the current voltage. 6. Turn on the air control switch, the work indicator light is on, and the oil-free air compressor starts to work. 7. Turn on the ozone switch, the ozone indicator will light up, and the ozone components will start to work. (The ozone generator above 15 grams needs to be adjusted. Degree knob to adjust the ozone output concentration.) The ozone silicone hose has ozone gas output. 8. If you need a timer switch to automatically control the whole machine, please purchase a microcomputer time controller separately 9. Ozone will be automatically decomposed into oxygen after 1-2 hours in the room. If people want to stay indoors for a long time, they need to If you can't smell the strong ozone smell, prevail. (Space disinfection) 10. After the disinfection is completed, please move the ozone generator to a dry and ventilated place, so that there is no accumulation of water in the box due to high humidity and high temperature environment. Affect the ozone generator.
