Industrial Water Treatment Frp Tank Sand Filter Pressure Vessel For RO Plant
Product Description
We have over 80 different sizes of pressure tanks from diameter 6 to 83 inch. All the products are made and tested according to the international standard which have passed NSF and CE certification. We manufacture ont only for our brand, but also offer OEM service for our customers.
1. Working Pressure: 0.1~0.6 MPa
2. TDS: ≤700mg/L
3. Production Capacity: 1~35m3/h
4. Raw water temperature: 1~40 degree
5. Operating temperature: 1~50 degree
6. Inlet water hardness: ≤12mmol/L
7. Outlet water hardness: ≤0.03mmol/L
8. regenerating resin should use NaCl, couldn't use iodised salt, calcium salt.
Advantages and Features
1. FRP tank is made of the advanced winding technique with high performance resin and fiber glass, the internal liner uses the
high performance environmental protection food grade and corrosion resisting FRP composite material.
2. FRP tanks, it has the characteristics of corrosion resisting, high temperature resisting, ageing resisting, light weight, high
strength, good quality, good appearance, convenient transportation installation, good seepage prevention, and long using life.`
3. FRP tank has upper and under openings, and flange connections, which can form a complete set with control valves in different
kinds of models and brands.
Specifications
| Specification | Size | Capacity | Opening | Length from top to bottom | Length | O.D. | Base Form | ||
| (Inch) | (mm) | (L) | Top open | (mm) | (mm) | (mm) | |||
| 817 | Φ 205× 445 | 11.3 | 2.5''NPSM | 446 | 432 | 206 | pp | ||
| 835 | Φ 205× 905 | 24.0 | 2.5''NPSM | 905 | 891 | 206 | pp | ||
| 844 | Φ 205× 1130 | 32.5 | 2.5''NPSM | 1131 | 1117 | 206 | pp | ||
| 1017 | Φ 255× 445 | 17.8 | 2.5''NPSM | 447 | 433 | 257 | pp | ||
| 1035 | Φ 255× 905 | 38.6 | 2.5''NPSM | 903 | 889 | 257 | pp | ||
| 1054 | Φ 255× 1390 | 61.9 | 2.5''NPSM | 1390 | 1376 | 257 | pp |
||
